Code the Client Component

Let’s now configure the client component. The client contains the signup page, and the background script which obtains the data from the user and passes it on to Catalyst.

The client directory by default contains:

The index.html file for the HTML code of the frontend application
The main.css for the CSS code
The main.js file for the JavaScript code
The client-package.json configuration file

We will be creating two new files in this directory.

We will be coding index.html, main.js, and main.css, as well as the new files.

Note: Please go through the code in this section to make sure you fully understand it.

Copy the code below and paste it in the respective files located in the client/ directory of your project using an IDE and save the files.


        index.html

            copy







         <!DOCTYPE html>
<html>
<head>
    <meta charset="UTF-8">
    <title>signup - label</title>
    <script src="https://www.zoho.com/crm/js/js-lib-file.js"></script>
   <script src="https://static.zohocdn.com/catalyst/sdk/js/2.0.0/catalystWebSDK.js"></script>
   <script src="/__catalyst/sdk/init.js"></script>
<style>
        *,
        *:before,
        *:after {
            box-sizing: border-box;
        }

        html {
            overflow-y: scroll;
        }

        body {
            background: #c1bdba;
            font-family: 'Titillium Web', sans-serif;
        }

        a {
            text-decoration: none;
            color: #1ab188;
            transition: .5s ease;
        }

        a:hover {
            color: #179b77;
        }

        .form {
            background: rgba(19, 35, 47, 0.9);
            padding: 40px;
            max-width: 600px;
            margin: 40px auto;
            border-radius: 4px;
            box-shadow: 0 4px 10px 4px rgba(19, 35, 47, 0.3);
        }

        .tab-group {
            list-style: none;
            padding: 0;
            margin: 0 0 40px 0;
        }

        .tab-group:after {
            content: "";
            display: table;
            clear: both;
        }

        .tab-group li a {
            display: block;
            text-decoration: none;
            padding: 12px;
            background: rgba(160, 179, 176, 0.25);
            color: #a0b3b0;
            font-size: 20px;
            float: left;
            width: 50%;
            text-align: center;
            cursor: pointer;
            transition: .5s ease;
        }

        .tab-group li a:hover {
            background: #179b77;
            color: #ffffff;
        }

        .tab-group .active a {
            background: #1ab188;
            color: #ffffff;
        }

        .tab-content>div:last-child {
            display: none;
        }

        h1 {
            text-align: center;
            color: #ffffff;
            font-weight: 600;
            margin: 0 0 30px;
        }

        label {
            position: absolute;
            -webkit-transform: translateY(6px);
            transform: translateY(6px);
            left: 13px;
            top: 8px;
            color: rgba(255, 255, 255, 0.5);
            transition: all 0.25s ease;
            -webkit-backface-visibility: hidden;
            pointer-events: none;
            font-size: 16px;
        }

        label .req {
            margin: 2px;
            color: #1ab188;
        }

        label.active {
            -webkit-transform: translateY(50px);
            transform: translateY(50px);
            left: 2px;
            font-size: 14px;
        }

        label.active .req {
            opacity: 0;
        }

        label.highlight {
            color: #ffffff;
        }

        input,
        textarea {
            font-size: 16px;
            display: block;
            width: 100%;
            /* height: 100%; */
            padding: 12px 10px;
            background: none;
            background-image: none;
            border: 1px solid #a0b3b0;
            color: #ffffff;
            border-radius: 0;
            box-sizing: border-box;
            transition: border-color .25s ease, box-shadow .25s ease;
        }

        input:focus,
        textarea:focus {
            outline: 0;
            border-color: #1ab188;
        }

        textarea {
            border: 2px solid #a0b3b0;
            resize: vertical;
        }

        .field-wrap {
            position: relative;
            margin-bottom: 40px;
        }

        .top-row:after {
            content: "";
            display: table;
            clear: both;
        }

        .top-row>div {
            float: left;
            width: 48%;
            margin-right: 4%;
        }

        .top-row>div:last-child {
            margin: 0;
        }

        .button {
            border: 0;
            outline: none;
            border-radius: 0;
            padding: 14px 0;
            font-size: 20px;
            font-weight: 600;
            text-transform: uppercase;
            letter-spacing: .1em;
            background: #1ab188;
            color: #ffffff;
            transition: all 0.5s ease;
            -webkit-appearance: none;
        }

        .button:hover,
        .button:focus {
            background: #179b77;
        }

        .button-block {
            display: block;
            width: 100%;
        }

        .forgot {
            margin-top: -20px;
            text-align: right;
        }
    </style>
</head>

<body>
    <div class="form">
        <ul class="tab-group">
            <li class="tab active"><a href="#signup">Sign Up</a></li>
            <li class="tab"><a href="#login">Log In</a></li>
        </ul>
        <div class="tab-content">
            <div id="signup">
                <h1>Sign up to Continue to EventApp</h1>
                <form>
                    <div class="top-row">
                        <div class="field-wrap">
                            <label> First Name<span class="req">*</span> </label>
                            <input id="firstname" type="text" required autocomplete="off" />
                        </div>
                        <div class="field-wrap">
                            <label> Last Name<span class="req">*</span> </label>
                            <input id="lastname" type="text" required autocomplete="off" />
                        </div>
                    </div>
                    <div class="field-wrap">
                        <label> Email Address<span class="req">*</span> </label>
                        <input id="email" type="email" required autocomplete="off" />
                    </div>
                    <button onclick="signupAction(this)" class="button button-block" />
                    Get Started
                    </button>
                </form>
            </div>
            <div id="login">

            </div>
        </div>
        <!-- tab-content -->

    </div>
    <!-- /form -->
    <script src="main.js"></script>
    <script>
        $(document).ready(function () {
            $('.form').find('input, textarea').on('focus', function (e) {
                var $this = $(this),
                    label = $this.prev('label');
                label.addClass('active highlight');
            });

            $('.form').find('input, textarea').on('blur', function (e) {
                var $this = $(this),
                    label = $this.prev('label');
                if ($this.val() == '') {
                    label.removeClass('active highlight');
                } else {
                    label.removeClass('highlight');
                }
            });

            $('.tab a').on('click', function (e) {
                e.preventDefault();
                $(this).parent().addClass('active');
                $(this).parent().siblings().removeClass('active');
                target = $(this).attr('href');
                $('.tab-content > div').not(target).hide();
                $(target).fadeIn(600);
            });
        });
    </script>
</body>
</html>

         View more


        main.js

            copy







         function signupAction(ele) {
    debugger;
    var firstName = document.getElementById("firstname").value;
    var lastName = document.getElementById("lastname").value
    var email = document.getElementById("email").value;
    var data = {
        "first_name": firstName,
        "last_name": lastName,
        "email_id": email,
        "platform_type": "web"
    };
    var auth = catalyst.auth;
    var signupPromise = auth.signUp(data);
    signupPromise
        .then((response) => {
            console.log(response.content);
        })
        .catch((err) => {
            console.log(err);
        });
}


         View more


        main.css

            copy







         html,
body {
	scroll-behavior: smooth;
	-webkit-scroll-behaviour: smooth;
}

.container {
	max-width: 960px;
}

.site-header {
	background-color: rgba(0, 0, 0, .85);
	-webkit-backdrop-filter: saturate(180%) blur(20px);
	backdrop-filter: saturate(180%) blur(20px);
}

.site-header a {
	color: #999;
	transition: ease-in-out color .15s;
}

.site-header a:hover {
	color: #fff;
	text-decoration: none;
}

.product-device {
	position: absolute;
	right: 10%;
	bottom: -30%;
	width: 300px;
	height: 540px;
	background-color: #333;
	border-radius: 21px;
	-webkit-transform: rotate(30deg);
	transform: rotate(30deg);
}

.product-device::before {
	position: absolute;
	top: 10%;
	right: 10px;
	bottom: 10%;
	left: 10px;
	content: "";
	background-color: rgba(255, 255, 255, .1);
	border-radius: 5px;
}

.product-device-2 {
	top: -25%;
	right: auto;
	bottom: 0;
	left: 5%;
	background-color: #e5e5e5;
}

.border-top {
	border-top: 1px solid #e5e5e5;
}

.border-bottom {
	border-bottom: 1px solid #e5e5e5;
}

.box-shadow {
	box-shadow: 0 .25rem .75rem rgba(0, 0, 0, .05);
}

.flex-equal > * {
	-ms-flex: 1;
	-webkit-box-flex: 1;
	flex: 1;
}

@media (min-width: 768px) {
	.flex-md-equal > * {
		-ms-flex: 1;
		-webkit-box-flex: 1;
		flex: 1;
	}
}

.overflow-hidden {
	overflow: hidden;
}

         View more

Create New Files

Create two new HTML files in the client/ directory and name them home.html and redirect.html.

Now, copy the code given below and paste them in the respective files.


        home.html

            copy







         <!doctype html>
<html lang="en">
<head>
 <meta charset="utf-8">
 <meta name="viewport" content="width=device-width, initial-scale=1, shrink-to-fit=no">
 <meta name="description" content="">
 <meta name="author" content="">
 <title>Welcome to Eventapp</title>
 <!-- Bootstrap core CSS -->
 <link href="https://stackpath.bootstrapcdn.com/bootstrap/4.4.1/css/bootstrap.min.css" rel="stylesheet" integrity="sha384-Vkoo8x4CGsO3+Hhxv8T/Q5PaXtkKtu6ug5TOeNV6gBiFeWPGFN9MuhOf23Q9Ifjh" crossorigin="anonymous">
 <!-- Custom styles -->
 <link href="product.css" rel="stylesheet">
</head>
<body>
 <nav class="site-header sticky-top py-1">
  <div class="container d-flex flex-column flex-md-row justify-content-center">
   <a class="py-2 d-none d-md-inline-block" href="#">
          <svg xmlns="http://www.w3.org/2000/svg" width="24" height="24" viewBox="0 0 24 24" fill="none" stroke="currentColor" stroke-width="2" stroke-linecap="round" stroke-linejoin="round" class="d-inline-block align-self-center"><circle cx="12" cy="12" r="10"></circle><line x1="14.31" y1="8" x2="20.05" y2="17.94"></line><line x1="9.69" y1="8" x2="21.17" y2="8"></line><line x1="7.38" y1="12" x2="13.12" y2="2.06"></line><line x1="9.69" y1="16" x2="3.95" y2="6.06"></line><line x1="14.31" y1="16" x2="2.83" y2="16"></line><line x1="16.62" y1="12" x2="10.88" y2="21.94"></line></svg>
        </a>
  </div>
 </nav>
 <div class="position-relative overflow-hidden p-3 p-md-5 m-md-3 text-center bg-light">
  <div class="col-md-5 p-lg-5 mx-auto my-5">
   <h1 class="display-4 font-weight-normal">Welcome to Event App</h1>
   <p class="lead font-weight-normal">Your one-stop destination to create, organize, and manage events!</p>
   <a class="btn btn-outline-secondary" href="#features">Features</a>
  </div>
  <div class="product-device box-shadow d-none d-md-block"></div>
  <div class="product-device product-device-2 box-shadow d-none d-md-block"></div>
 </div>
 <div class="d-md-flex flex-md-equal w-100 my-md-3 pl-md-3" id="features">
  <div class="bg-dark mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center text-white overflow-hidden">
   <div class="my-3 py-3">
    <h2 class="display-5">Trouble-free event management experience</h2>
    <p class="lead">Event App makes sure you have a seamless and an experience in organizing events by automating your tasks</p>
   </div>
   <div class="bg-light box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
  <div class="bg-light mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center overflow-hidden">
   <div class="my-3 p-3">
    <h2 class="display-5">Create and manage events of all types</h2>
    <p class="lead">Create events, group them in categories, customize them and add details as you need</p>
   </div>
   <div class="bg-dark box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
 </div>
 <div class="d-md-flex flex-md-equal w-100 my-md-3 pl-md-3">
  <div class="bg-light mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center overflow-hidden">
   <div class="my-3 p-3">
    <h2 class="display-5">Invite people and keep track of their RSVPs</h2>
    <p class="lead">Invite people through various platforms to your events, record their RSVPs and obtain a final count of the attendees to your events</p>
   </div>
   <div class="bg-dark box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
  <div class="bg-dark mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center text-white overflow-hidden">
   <div class="my-3 py-3">
    <h2 class="display-5">Customize your event invites in your own creative ways</h2>
    <p class="lead">Embedd images, videos, and links in your event invitations, and customize the designs of the event invites based on their contexts</p>
   </div>
   <div class="bg-light box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
 </div>
 <div class="d-md-flex flex-md-equal w-100 my-md-3 pl-md-3">
  <div class="bg-dark mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center text-white overflow-hidden">
   <div class="my-3 py-3">
    <h2 class="display-5">Integrate Event App with various social media platforms</h2>
    <p class="lead">Share your events on Facebook, Twitter, Instagram, Yelp, LinkedIn and other social media platforms</p>
   </div>
   <div class="bg-light box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
  <div class="bg-light mr-md-3 pt-3 px-3 pt-md-5 px-md-5 text-center overflow-hidden">
   <div class="my-3 py-3">
    <h2 class="display-5">Track sales analytics and performances of your events</h2>
    <p class="lead">Event App also provides you reports and statistics of your event performances for your convenience</p>
   </div>
   <div class="bg-white box-shadow mx-auto" style="width: 80%; height: 300px; border-radius: 21px 21px 0 0;"></div>
  </div>
 </div>
 <footer class="container-fluid py-5">
  <div class="row">
   <div class="col-md-7 p-lg-5 mx-auto text-center">
    <h3 class="display-6 font-weight-normal">Get started with Event App today!</h3>
   </div>
  </div>
 </footer>
</body>
</html>

         View more


        redirect.html

            copy







         <!doctype html>
<html>
<head>
<meta charset="UTF-8">
<title>redirect.html</title>
</head>
<body>
	<h2>Please check you email for a product tour</h2>
</body>
</html>

         View more

Let us quickly discuss the client files:

index.html: Includes the sign-up code of the Event app
main.js: Contains the script for the sign-up page. This obtains the data from the form on the client page and passes it on to the event listener that listens for the user sign-up event.
home.html: Contains the code of the page the user will be navigated to, from the onboarding email they receive.
redirect.html After the user completes setting up their password to access Event App, they will be redirected to this page.

You must now enable this redirection to redirect.html by default. You can do this by configuring the client-package.json configuration file in the /client directory.

Copy the code given below and replace it with the default code present in the client-package.json file.


        client-package.json

            copy








	{
	"name": "EventAppClient",
	"version": "0.0.1",
	"homepage": "index.html",
	"login_redirect":"redirect.html"
	}

         View more

The client component of your Catalyst project is now configured successfully.

Last Updated 2023-05-10 13:52:27 +0530 +0530

Client Directory
